MSI P7N SLI-FI MS-7380
MSI P7N SLI-FI Socket 775 NVIDIA nForce 750i SLI ATX Intel Motherboard.
SPECIFICATIONS:
Socket |
LGA 775 |
Chipset Type |
NVIDIA nForce 750i SLI |
Compatible Processors |
Core 2 Quad / Core 2 Extreme / Core 2 Duo |
Bus Speed |
1333/1066MHz |
Storage |
PATA: 2 x ATA100 4 Dev. Max
SATA 3Gb/s: 4
SATA RAID:
0/1/0+1/5/JBOD |
Memory |
Number of Memory Slots: 4 x 240pin
Memory Standard: DDR2 800
Maximum Memory Supported: 8GB
Channel Supported: Dual Channel |
Onboard Video Chipset |
None |
Audio |
Realtek ALC888
, 8 channels |
Networking |
Realtek 8211BL,
10/100/1000Mbps |
Expansion Slots |
1 x PCI Express 2.0 x16
2 x light-blue PCI Express X16 slot (PCI_E2 & PCI_E3) support PCI Express X8 mode only
PCI Slots: 2 |
Rear Panel Ports |
PS/2: 2
Video Ports: DVI
USB 1.1/2.0: 4 x USB 2.0
IEEE 1394: 1 x IEEE 1394a
S/PDIF Out:
1 x Optical
Audio Ports:
6 ports |
Onboard USB |
4 x USB 2.0 |
Form factor |
ATX,
12.0" x 9.6" |
Package Includes:
P7N SLI-FI Motherboard, SATA cables, IDE cables, I/O Shield, Drivers CD, Quick Installation Guide, and CrossFire Bridge.
|
|
