Socket |
AM3 |
Chipset Type |
AMD 785G and SB710 |
Compatible Processors |
64bit AMD Phenom II CPU |
Bus Speed |
HyperTransport 3.0 supporting speed up to 2.6GHz |
On-Board IDE
|
. One IDE port by AMD SB710
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
- Can connect up to two IDE devices
SATA 3Gb/s: 4 |
On-Board SATA |
. 5 SATA II ports by AMD® SB710
. 1 eSATA II port by AMD® SB710
- Supports storage and data transfers at up to 3Gb/s |
Memory |
Number of Memory Slots: 4 x 240pin
Memory Standard:
DDR3 800/1066/1333/1600
Maximum Memory Supported: 16GB |
Internal I/O Connectors
|
- ATX 24-pin power connector
- ATX 4-pin 12V CPU power connector
- CPU x 1 / System x 1 FAN connectors
- CD-in connector
- Front panel audio connector
- Front panel connector
- Chassis intrusion switch connector
- 3 x USB 2.0 connector support additional 6 ports
- 1 x Floppy disk drive connector
- 5 x Serial ATA II connectors
- 1 x ATA133 connector
- 1 x SPDIF-out connector
- 1 x Serial port connector
- 1 x Parallel port connector
- Clear CMOS jumper
- OC Switch
- 1 x TPM module header |
Audio |
. Chipset integrated by Realtek® High-End Audio chipset
- True Blu-ray Audio Support
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec |
Networking |
. Realtek PCI-E GbLAN controller 8111DL
- Integrated Fast Ethernet MAC and PHY in single chip
- Supports 10Mb/s, 100Mb/s and 1000Mb/s
- Compliance with PCI-Express Bus specification v1.0a |
Expansion Slots |
. 1 PCI Express x16 slot (PCI Express Bus SPEC V2.0 compliant)
. 1 PCI Express x1 slot
. 2 PCI slots, support 3.3V/ 5V PCI bus Interface. |
Rear Panel Ports |
- 1 x PS/2 keyboard or mouse
- 1 x 6 in 1 audio jack
- 6 x USB 2.0 ports
- 1 x RJ45 LAN jack
- 1 x eSATA port
- 1 x DVI-D port
- 1 x Graphic Card port
- 1 x HDMI port |
Onboard USB |
6 x USB 2.0 |
Form factor |
24.4cm(L) x 24.4cm(W) Micro-ATX |
