$129.95









ECS 945P-A (V1.1)

Socket 775 PCI Express for Intel Pentium 4 processor

  • 945P-A v1.1 motherboard incorporates the Intel Pentium4/PentiumD Processor in LGA775-pin package couple with Intel 945P and ICH7 chipset that support the fastest 1066MHz FSB to set a new benchmark for an effective desktop platform solution.
  • Special Features:

    FSB 1066MHz
    Supports the latest 1066MHz front side bus Intel Pentium 4 CPU

    8-Channel Audio
    Enable premium home theater experience through the PC,with support for all major audio format.

    ATI Crossfire
    Supports ATI Radeon Xpress 200 CrossFire

    Dual Channel DDR2 667
    4DDR2 DIMMs support dual-channel DDR2 667, expanding memory bandwidth to 10.7GB/s and supporting up to 4GB of memory. Dramatically shortens memory access time leads for extremely quick results.

    64bit support
    Allows platforms to access more memory and larger files. Large memory intensive applications, such as audio and video encoding, complex engineering programs and games, can see dramatic performance increases.

    PCI Express
    Delivers up to a 4x increase in graphics and 2x I/O bandwidth for smooth multimedia performance.

    Dualcore
    Dual-core is basically two separate processors on a single chip. Those two processors can outperform single-core processors on most multithreaded applications while running at lower clock speeds and consuming less power.

    Color Map
    Color-coded pin headers and slots make it easy to match plug

    Serial-ATA 2
    Double bus bandwidth which provides blazingly high disk performance, ensuring your computing experience will be faster, more reliable, and completely with current and future hardware and software.

    Specification:

    CPU
    LGA775 socket for latest Intel Pentium 4 / Pentium D processor
    FSB 1066/800/533 MHz
    Support Hyper-Threading Technology

    CHIPSET
    Intel 945P & ICH7
    North Bridge: Intel 945P
    South Bridge: Intel ICH7

    MEMORY
    Dual-channel DDR2 memory architecture
    4 x 240-pin DDR2 DIMM socket support up to 4 GB
    Support DDR2 667/533/400 DDR2 SDRAM

    EXPANSION SLOT
    2 x PCI Express x16 slot
    1 x PCI Express x1 slots *
    3 x PCI slots
    *when use two PCI Express VGA card, this slot is disable

    STORAGE
    Supported by Intel ICH7
    -- 2 x Ultra DMA100/66 devices
    -- 4 x Serial ATA2 devices

    AUDIO
    Realtek ALC880 8-channel audio CODEC

    LAN
    Realtek RTL8110S Gigabit Fast Ethernet Controller

    REAR PANEL I/O
    1 x PS/2 keyboard & PS/2 mouse connectors
    4 x USB ports
    1 x RJ45 LAN connector
    1 x Serial port (COM1)
    1 x Audio port (Line-in,4x Line-out, Mic_in)
    1 x Parallel port (LPT1)

    INTERNAL I/O CONNECTORS & HEADERS
    1 x 24-pin ATX Power Supply connector
    1 x 4-pin ATX 12V connector
    1 x IrDA for SIR header
    1 x FDD connector supports two 360K~2.88MB FDDs
    1 x IDE connectors
    4 x Serial ATA connectors
    1 x Speaker header
    2 x USB 2.0 headers support additional 4 USB ports
    1 x Front panel switch/LED header
    1 x Front panel audio header
    CD in header
    CPUFAN/NB_FAN/SYSFAN connectors

    SYSTEM BIOS
    AMI BIOS with 4Mb Flash ROM
    Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
    Supports ACPI revision 1.0 specification

    FORM FACTOR
    ATX Size 305mm*244mm

    For CPU Support click HERE

    Also included:

    Manual. Utilities CD with extra softwares. I/O faceplate. HDD& FDD cables.
